• 60% shrinkage ratio – conforms to high transitions
Reduces inventory & logistics costs.
• Resists a wide range of environmental and mechanical forces
Reliable, moisture-proof seal!
• Specially formulated sealant
Ensures a strong bond & tight seal to virtually any substrate. Maintains its elasticity and sealing characteristics over a wide temperature range.
• Sealing adhesive automatically flows and repairs minor mechanical damages .Saves time.
• Usable also when service pipe is not concentric with the casing. Highly versatile.
• No special equipment required
Makes installation fast and easy. Keeps installation costs low.
Product selection guide
Max operating temperature | 30°C (86°F) |
Compatible line coatings | PE, PP, FBE, Tape, Coal tar, Asphalt, Plastics |
| Min preheat temperature | 60°C (140°F) |
Recommended pipe preparation | ST3 or SA21 / |
Product properties
Backing
Property | Test method | Typical Value |
Bursting strength | DIN 30672 | 3200 N |
Adhesive
Softening point | ASTM E-28 | 78ºC (172ºF) |
Shear strength | EN12068 | 8 N/cm |
Peel strength | EN12068 | 9 N/cm |
Product dimensions-Standard Ordering options
Product thickness
Backing (as supplied) | 1mm |
Adhesive (as supplied) | 0.6mm |
Application table
Pipe diameter DN(mm) | Casing diameter(mm) | Max Casing diameter |
| 32 | 92 | 132 |
| 48 | 108 | 148 |
| 60 | 120 | 160 |
| 76 | 136 | 176 |
| 89 | 149 | 189 |
| 108 | 168 | 208 |
| 114 | 174 | 214 |
| 133 | 193 | 233 |
| 159 | 219 | 259 |
| 168 | 228 | 268 |
| 219 | 279 | 319 |
Size can be made for any specific casing diameter | ||
