性能指标 DATA SHEET
| 产品名称 Product name | 试验项目 Test name | 标准要求 Standard requirement | 试验结果 result | 评注 remarks |
| 8.7/15KV户内、 户外终端及中间 连接 8.7/15KVindoor , outdoor termination and intermediate connectors | 工频耐压 p.f withstand voltage test | 45KV，1min不闪络，不击穿 45kv no flash and no breakdown | 45KV，1min未闪络，未击穿 45kv no flash and no breakdown | 通过 passed |
| 局部放电试验 test of partial discharge | 13KV≤ 20pc | 13kv时，3PC | 通过 passed | |
| 负荷循环i试验，3个周期load circulation test | 5h加热时，3h冷却。加热时 导体温度95℃ 5h heated.3h cooled.conductor heated to 95℃ | 在导体温度（ 90-95℃)下共 经受3个循环 Conductor heated to 90- 95℃, total 3 circulations | 通过 passed | |
| 局部电压i试验 partial dischargetest | 13kv时放电里≤20pc | 13kv时，3PC | 通过 passed | |
| 冲击电压i试验 impulse voltagetest | 105kv、正负极性各10次·允 许闪络一次,但不计入总试 验次数105kv, on negative and positive poles applied each 10times, one flashover is allowed but not calculated | 105kv，未闪络，未击穿 105kv no flash and no breakdown | 通过 passed | |
| 负极性直流电压i试验 test of the negative pole | 52Kv，15min不闪络,不击穿 52KV，15min no flash and no breakdown | 52kv，15min未闪络，未击穿 52Kv，15min no flash and no breakdown | 通过 passed | |
| 4h工频电压i试验 4h power voltage test | 35Kv，4h 不闪络，不击穿 35KV，4h no flash and no breakdown | 35kv，4h未闪络，未击穿 35Kv，4h no flash and no breakdown | 通过 passed |
规格尺寸 SIZE
| 产品名称 Product mane | 型号规格 Mode&specification | 适用电缆截面积mm2 The applicable section |
| 8.7/15KV单芯户内终端 one-core indoor terminal | TNPE-NLY-10/1.1 | 25-50 |
| TNPE-NLY-10/1.2 | 70-120 | |
| TNPE-NLY-10/1.3 | 150-240 | |
| TNPE-NLY-10/1.4 | 300-400 | |
| 8.7/15KV单芯户外终端 one-core cold outdoor terminal | TNPE一WLY-10 /1.1 | 25-50 |
| TNPE一WLY-10 /1.2 | 70-120 | |
| TNPE一WLY-10 /1.3 | 150-240 | |
| TNPE一WLY-10 /1.4 | 300-400 | |
| 8.7/15KV单芯中间连接 one-core intermediate connector | TNPE一JLY- 10 / 1.1 | 25-50 |
| TNPE一JLY- 10 / 1.2 | 70-120 | |
| TNPE一JLY- 10 / 1.3 | 150-240 | |
| TNPE一JLY- 10 / 1.4 | 300-400 | |
| 8.7/15KV三芯户内终端 three-core indoor terminal | TNPE-NLY-10 / 3.1 | 25-50 |
| TNPE-NLY-10 / 3.2 | 70-120 | |
| TNPE-NLY-10 / 3.3 | 150-240 | |
| TNPE-NLY-10 / 3.4 | 300-400 | |
| 8.7/15KV三芯户外终端 three-core cold outdoor terminal | TNPE一WLY-10 / 3.1 | 25-50 |
| TNPE一WLY-10 / 3.2 | 70-120 | |
| TNPE一WLY-10 / 3.3 | 150-240 | |
| TNPE一WLY-10 / 3.4 | 300-400 | |
| 8.7/15KV三芯中间连接 three-core intermediate connector | TNPE-JLY- 10 / 3.1 | 25=50 |
| TNPE-JLY- 10 / 3.2 | 70-120 | |
| TNPE-JLY- 10 / 3.3 | 150-240 | |
| TNPE-JLY- 10 / 3.4 | 300-400 |
