性能指标 DATA SHEET
| 产品名称 Product name | 试验项目 Test name | 标准要求 Standard requirement | 试验结果 result | 评注 remarks |
| 35KV户内、户 外终端及中间 连接 35KVindoor: outdoor termination and intermediate connectors | 工频耐压 p.f withstand voltage test | 105KV，1min 不闪络不击穿 105kv no flash and no breakdown | 105Kv，1min未闪络，未击 105kv no flash and no breakdown | 通过 passed |
| 局部放电试验 test of partial discharge | 39KV下放电里≤10pC | 39kv下组合试样放电里4PC | 通过 passed | |
| 负荷循环试验，3个周期load circulation test | 5加热时，3h冷却。加热时 导体加热95-100C每一循环 为8h 5h heated. 3h cooled. conductor heated to 95-100C | 5h加热时，3h;冷却。加热时导 体加热95-100℃每一循环为s8h Conductor heated to 90- 95℃,total 3 circulations | 通过 passed | |
| 局部电压试验 partial discharge test | 39kv时放电里≤10pc | 39kv下组合试样放电里4PC | 通过 passed | |
| 冲击电压试验 impulse voltagetest | 250kv，正负极性各10次,不 闪络,不击穿 250kv, on negative and positive poles applied each 10times, one flashover is allowed but not calculated | 250kv，未闪络，未击穿 250kv no flash and no breakdown | 通过 passed | |
| 负极性直流电压i试验 test of the negative pole | 156Kv，15min 不闪络不击穿 156KV，15min no flash and no breakdown | 156kv，15min未闪络,未击穿 156KV，15min no flash and no breakdown | 通过 passed | |
| 工频电压i试验 power voltage test | 104KV，4h 不闪络，不击穿 104KV，4h no flash and no breakdown | 104kv，4h未闪络,未击穿 104KV，4h no flash and no breakdown | 通过 passed |
规格尺寸 SIZE
| 产品名称 Product mane | 型号规格 Mode&specification | 适用电缆截面积mm2 The applicable section |
| 26/35KV单芯户内终端 one-core indoor terminal | NLY-35/1.1 | 35-70 |
| NLY-35/1.2 | 95-150 | |
| NLY-35/1.3 | 185-300 | |
| NLY-35/1.4 | 400-500 | |
| NLY-35/1.5 | 630 | |
| 26/35KV单芯户外终端 one-core cold outdoor terminal | WLY-35/1.1 | 25-50 |
| WLY-35/1.2 | 70-120 | |
| WLY-35/1.3 | 150-240 | |
| WLY-35/1.4 | 300-400 | |
| WLY-35/1.5 | 3630 | |
| 26/35KV单芯中间连接 one-core intermediate connector | JLY-35/1.1 | 25-50 |
| JLY-35/1.2 | 70-120 | |
| JLY-35/1.3 | 150-240 | |
| JLY-35/1.4 | 300-400 | |
| JLY-35/1.5 | 630 | |
| 26/35KV三芯户内终端 three-core indoor terminal | NLY-35/3.1 | 25-50 |
| NLY-35/3.2 | 70-120 | |
| NLY-35/3.3 | 150-240 | |
| NLY-35/3.4 | 300-400 | |
| NLY-35/3.5 | 630 | |
| 26/35KV三芯户外终端 three-core cold outdoor terminal | WLY-35/3.1 | 25-50 |
| WLY-35/3.2 | 70-120 | |
| WLY-35/3.3 | 150-240 | |
| WLY-35/3.4 | 300-400 | |
| WLY-35/3.5 | 630 | |
| 26/35KV三芯中间连接 three-core intermediate connecto | JLY- 35/3.1 | 25-50 |
| JLY- 35/3.2 | 70-120 | |
| JLY- 35/3.3 | 150-240 | |
| JLY- 35/3.4 | 300-400 | |
| JLY- 35/3.5 | 630 |
